Single-ram pit lift XT with swing-arm support and arm extensions, 3.5 t, 1900 mm stroke (P1-35.19-XT, PITLIFT)
Complete single-ram XT lift with swing-arm support, support arm extensions, hydraulic power unit, control box and cover for the pitlift plastic cassette.
- Capacity: 3.5 t
- Capacity with support arm extensions: 3.2 t
- Stroke: 1900 mm
- Ram diameter: 125 mm
- Extension length without arm extensions: 540 to 820 mm
- Extension length with arm extensions: 540 to 1130 mm
- Centre beam mounting: 640 mm
- Swing-arm support, support arms and arm extensions electroplated galvanised, Sport support plates (55)
- Hydraulic oil volume: 50 litres, oil not included
- Without CE-Stop
